Free Shipping Automatic Voltage Regulator AVR VR6

Part Number:VR6
Application:

The AVC63-12B2 regulate the level of excitation supplied to the field of a conventional, brushless, synchronous generator. Regulation is achieved by sensing the generator output voltage, converting it to a dc signal, and comparing the signal to a reference voltage.

• SHUNT EXCITED:90-153 Vac 400Hz 1 OR 3 PHASE
• PMG EXCITED:90-153 Vac 400Hz 3 PHASE
• SENSING INPUT:184-264 Aac 400Hz 1 OR 3 PHASE
• CT INPUT:1 OR 5 Aac 400Hz
• ACC INPUT:+/-3 Vdc
• OUT PUT:63 Vdc @ 12 Adc

AVAILABLE OPTIONS:

• Remote Voltage Adjust,
• Inrush Current Reduction Module,
• Excitation Disable, Exciation Limiter,
• VAR/Power Factor Control,
• Current Boost System (CBS),
• Manual Voltage Control (MVC)
