24V 180A
Part Number:Genie 19550GT 19550
Application:
Double Pole, Changeover Contacts Magnetic Blowouts
Coil Power – 11 to 15W
Rated Voltage of Contact Circuit - 6 to 80 Volts DC
Dielectric Voltage Strength - 50Hz 1000V AC 1min
Current Volt Drop of Main Contact at 100A - Not above 80mV
Operating time, Contact Makes & Contact Brakes - >30ms
Mechanical Life - 100 thousand times
Electric Life - 20 thousand times
