Free Shipping Automatic Voltage Regulator AVR for Marelli Brushless M16FA655A Mark V
by Marelli
Save 44%
Original Price
$159.00
Current Price
$89.00
SKU Jeenda022387
Part Number:M16FA655A Mark V
- Marelli 10005388
- Marelli Mark V
- Marelli M16FA655A
- Olympian 10000-61859
TECHNICAL DATA for M16FA655A Marelli AVR:
- REGULATION ACCURACY: +/- 0.5% rated steady-state conditions
- VOLTAGE DRIFT:+/- 0.5 %, voltage change, for 50°C T amb change
- RESPONSE TIME: 1 cycle
- OPERATING TEMPERATURE: -30 °C ÷ +70 °C
- EXCITER FIELD RESISTANCE: 8 Ω (min) ÷ 20 Ω(max)
- INPUT/OUTPUT DATA of M16FA655A Marelli Automatic voltage regulator :
- -PROVIDE VOLTAGE:170 -270 V
- -POWER PROVIDE:350 VA (max)
- -POWER DISSIPATED: 15 W (max)
- -VOLTAGE SENSING: 170 - 270 V
- -OUTPUT VOLTAGE (DC):30 V
- -OUTPUT CURRENT (DC): 5 A (max, continuous)
- -OUTPUT CURRENT (DC): 8 A (max forcing one minute)
