Technical Specifications:
- Display: LCD(132*64)
- Operation Panel: Silicon Rubber
- Language: Chinese & English
- Digital Input: 7
- Relay Output: 6
- Analogue Input: 2
- AC System: 1P2W/2P3W/3P3W/3P4W
- Alternator Voltage: (15～360)V(ph-N)
- Alternator Frequency: 50/60Hz
- Monitor Interface: RS485
- Programmable Interface: USB/RS485
- DC Supply : DC(8～35)V
- Case Dimensions(mm): 135*110*44
- Panel Cutout(mm): 116*90
- Operating Temp.: (-25~+70)℃
- 132x64 LCD with backlight, selectable language interface (Chinese and English), push-button operation;
- Hard-screen acrylic material been used to protect screen with great wear-resisting and scratch-resisting functions.
- Silicone panel and pushbuttons can be used in extreme temperature environment.
- RS485 communication interface enable “Three remote functions” (remote control, remote measuring and remote communication) according to MODBUS protocol.
- Suitable for 3-phase 4-wire, 3-phase 3-wire, single phase 2-wire, and 2-phase 3-wire systems with voltage 120/240V and frequency 50/60Hz;
- Collects and shows mains 3-phase voltage/frequency, generator 3-phase voltage/frequency,
- Machine room temperature can be collected, if temperature is too high, air conditioner in the machine will be started;
- Battery pack voltage(48V) can be collected, if battery pack is under voltage, generator will be started to charge the battery;
- 6 start conditions can be grouped at random: mains abnormal signal, remote start signal, mains abnormal and temperature of machine room is high, mains abnormal and battery pack voltage is low, scheduled start, and cycle start/stop;
- 6 relay output ports, including 1 start output, 1 fuel output (programmable), 4 programmable outputs, in which programmable output port 4 shares the same port with input port 5 (can be set);
