- Display VFD
- Operation Panel Rubber
- Language Chinese & English
- Digital Input 8
- Relay Output 8
- Analogue Input 5
- AC System 1P2W/2P3W/3P3W/3P4W
- Alternator Voltage (15~360)V(ph-N)
- Alternator Frequency 50/60Hz
- Monitor Interface RS485
- Programmable Interface USB/RS485
- DC Supply DC(8～35)V
- Case Dimensions(mm) 242*186*53
- Panel Cutout(mm) 214*160
- Operating Temp. (-40~+70)℃
PERFORMANCE AND CHARACTERISTICS
- With ARM-based 32-bit SCM, high integration of hardware and more reliable.
- Graphics dot-matrix VFD with large screen, multilingual interface (including English, Chinese or other languages) which can be chosen at the site, making commissioning convenient for factory personnel.
- Improved LCD wear-resistance and scratch resistance due to hard screen acrylic.
- Silicon panel and pushbuttons for better operation in high/low temperature environment.
- RS485 communication port enables remote control, remote measuring, and remote communication via ModBus protocol.
- ETHERNET communication port enables ETHERNET monitoring. (controller must be with ETHERNET port)
- Equipped with SMS (Short Message Service) function. When genset is alarming, controller can send short messages via SMS automatically to max. 5 telephone numbers. Besides, generator status can be controlled and checked using SMS.
- Fitted with CANBUS port and can communicate with J1939 genset. Not only can monitor frequently-used data (such as water temperature, oil pressure, engine speed, fuel consumption and so on) of genset, but also control start, stop, raising speed and speed droop via CAN BUS port. (need controller with CAN BUS port)
- Suitable for 3-phase 4-wire, 3-phase 3-wire, single phase 2-wire, and 2-phase 3-wire systems with voltage 120/240V and frequency 50/60Hz.
