Part Number: OMEW160151H3043(CW), OMEW160-151H3043, 151H3043
Part Name: Hydraulic Motor
Specification:
Type: OMEW
Size: 160
Geometric displacement: 155.4cm³/[9.51in] Max speed cont: 375 rpm Max speed int: 470 rpm Max torque cont: 410Nm/[[3630lbf in] Max torque int: 430Nm/[3810lbf in] Max output power cont: 12kW/[16.1hp] Max output power int: 15kW/[20.1hp] Max pressure drop cont: 200bar/[2900psi] Max pressure drop int: 210bar/[3045psi] Max pressure drop peak: 280bar[4060psi] Max oil flow cont: 60L/min Max oil flow int: 75L/min Max starting pressure with unloaded shaft: 7bar/[100psi] Min starting torque at max press drop cont: 360Nm/[3190lbf in] Min starting torque at max press drop int: 380Nm/[3360lbf in]
