Deep Sea DSE5210 Auto Start Control Module

Full integration into new and existing building management systems
The module also provides excellent engine monitoring and protection features
Remote module configuration using PC software
Displays fault conditions on the LCD display and via the LED indicators on the front.
Dimensions: 240mm x 172mm ; Cut-out Size: 220mm x 160mm  DC Supply: 8-35V
The DSE5210 is an Automatic Start Control Module designed to automatically start and stop diesel and gas generating sets that include on electronic engines. The module also provides excellent engine monitoring and protection features.

The module has the ability to monitor under-speed, over speed, charge failure, emergency stop, low oil pressure, high engine temperature, fail to start, fail to stop, under/over generator volts, over current, under/over generator frequency, low/high DC battery volts, low fuel alarm and loss of the speed sensing signal. The module displays fault conditions on the LCD display and via the LED indicators on the front.

FEATURES:

Automatic start

Automatic load transfer

Configurable inputs

Configurable outputs

Configurable alarms & timers

Digital inputs

Analog inputs

Back-lit character LCD display

Engine protection

Front panel mounting

PC configurable

Front panel programming

Remote monitoring

RS485 remote communications (to be specified on ordering)

Modbus RTU

Engine history event log

LED alarm indication

LCD alarm indication

SMS messaging

Hid till lit alarm icons

Engine exercise mode

Magnetic pick-up

BENEFITS:

Full integration into new and existing building management systems

In-built engine diagnostics removes the requirement for service equipment

License-free PC software

Modules help to improve the life cycle of engine starter motors

On-site module configuration to match user requirements

Remote module configuration using PC software

Modules send SMS messages to engineers to notify specific engine problems (GSM Modem and SIM Card required)

User-friendly set-up and button layout
