ESD-5330-CE Speed Control for GAC

ESD5300 Series ¡§C Analog Governor

The ESD5300 Series speed control unit is designed to precisely control engine speed and provide fast precise response to transient engine loads. This speed control is intended to be used with all GAC Actuators including the ACB2001. A complete closed loop control system is formed with the addition of a magnetic pickup signal sensing engine speed and 24 Volt DC power.

ESD5330 - (Isochronous, Variable, & Droop Operation / 2 Element Speed Switch / Speed Ramping / Stating Fuel Control / Dual Gain / Unique Actuator Power Drive Circuit / Soft Coupling)

Features:
A Two Element Speed Switch
Speed Ramping Idle to Operating Speed
Starting Fuel Control for Lower Engine Exhaust Emissions
A Unique Actuator Power Drive Circuit
Accessory Inputs for Load Sharing
Variable Speed Governing
Protection Against Reverse Battery Voltage
Protection Against Transient Voltage
*Enhanced Start Circuit for Large Bore Engines (ESD5340)
