32mm 1/2 BSP Orbital Motor OMS80-151F0500 151F0500 OMS80151F0500
$390.00
SKU HP61319-JND
Part Name: Hydraulic Orbital Motor
Manufacturing Part Number: OMS80 - 151F0500, 151F0500, OMS80151F0500
Specification:
Specification:
Type: OMS
Motor Size: 80
Geometric displacement: 80.5cm³/[[4.91in]
Max speed cont: 810 rpm
Max speed int: 1000 rpm
Max torque cont: 240Nm/[2120lbf in]
Max torque int: 310Nm/[[2740lbf in]
Max output power cont: 15.5kW/[[20.8hp]
Max output power int: 19.5kW/[26.2hp]
Max pressure drop cont: 210bar/[3050psi]
Max pressure drop int: 275bar[3990psi]
Max pressure drop peak: 295bar/[4280psi]
Max oil flow cont: 65L/min
Max oil flow int: 80L/min
Max starting pressure with unloaded shaft: 12bar/[175psi]
Min starting torque at max press drop cont: 180Nm/[1590lbf in]
Min starting torque at max press drop int: 235Nm/[2080lbf in]
Max inlet pressure cont: 230bar/[3340psi]
Max inlet pressure int: 295bar/[4280psi]
Max inlet pressure peak: 300bar/[[4350psi]
Max return pressure with drain line cont: 140bar/[2030psi]
Max return pressure with drain line int: 175bar/[2540psi]
Max return pressure with drain line peak: 210bar/[3050psi]
