Automatic Voltage Regulator AVR EA05AF Original Parts for Kutai
Automatic Voltage Regulator AVR EA05AF Original Parts for Kutai
Regular price
$280.00 USD
Regular price
$280.00 USD
Sale price
$280.00 USD
Shipping calculated at checkout.
Description:
EA05AF 5 Amp Full Wave self-excited brushless type genset voltage regulator is a universal AVR and?compatible replacement for Onan VR21 series regulators
Parameter:
*< ¡À 1% Regulation
*220VAC Full Wave Rectifier
*Max. Output Voltage >170 VDC
*Under Frequency Protection
*Soft Start Voltage Ramping
*Under Frequency Protection
*Built-in High Breaking Capacity Fuse
Specification:
| Sensing & Power Input | Voltage 160~260 VAC, 1 Phase 2 Wire Frequency 50/60 Hz Selectable |
| Output | Voltage Max. 170 VDC @ 240 VAC input Current Continuous 5A, Intermittent 7A for 10 sec.? Resistance Min. 9 ¦¸ , Max. 100 ¦¸ |
| Voltage Regulation | < ¡À 1% (with 4% engine governing) |
| Voltage Build-up | More then > 5 VAC Residual voltage needed |
| External Volts Adjustment | ¡À10% with 5 K¦¸ 1 watt trimmer |
| Soft Start Ramp Time | 2 sec. |
| Unit Power Dissipation | Max. 8 Watt |
| Thermal Drift | 0. 03% per ¡ãC change in AVR ambient |
| Under Frequency Protection | For 60 Hz knee point set at 55 Hz (Factory Settings)? For 50 Hz knee point set at 45 Hz (Factory Settings) |
| Environment | Vibration : 3. 3 G @ 100~2 KHz Relative Humidity : < 95% Operating Temperature : -40~65 ¡ãC Storage Temperature : -40~80 ¡ãC |
| AVR Controls Functions | VOLTS : Voltage Adjustment STAB : Stability Adjustment U/F : To Set the U/F Knee Point (U/F: Under Frequency Protection) |
| Dimensions | 150. 0(L) x 100. 0(W) x 74. 0(H) mm |
