Automatic Voltage Regulator AVR EA45A220F for Kutai

Sensing & Power Input

Voltage 170-265 Vac 1 phase 2 wire
Frequency 50/60 Hz selectable

Output (at 220 Vac input)

Voltage
EA45A220FL : Max. 180 Vdc
Current
Continuous 45A, Intermittent 60A for 10 sec.
Resistance
EA45A220FL : Min. 2.7 ohms

Volts Regulation

< +/-1% (with 4% engine governing)

Build Up Voltage*

Residual volts at AVR terminal > 5 Vac @ 25 Hz

External Volts Adjustment

+/- 20%

Under Frequency Protection
(Factory Knee Point Setting)

50 Hz system presets knee point at 45 Hz
60 Hz system presets knee point at 55 Hz

Environment

Operation Temperature : -40 - +60 ¡ãC
Storage Temperature : -40 - +85 ¡ãC
Relative Humidity : Max. 95%?
Vibration : 3 Gs @ 100-2K Hz

Dimensions

330.0 (L) x 189.0 (W) x 180.0 (H) mm

Weight

EA45A220FL : 5.2 Kg +/- 2%
