Automatic Voltage Regulator AVR EA5K3 for Kutai

Sensing Input

Voltage 16 to 25 VAC 50/60 Hz 1 phase 2 wire

Power Input

Voltage 60 to 100 VAC 50/60 Hz 1 phase 2 wire

Output

Voltage Max. 100 Vdc @ 85 VAC
Current Continuous 3A Intermittent 5A for 60 sec.
Resistance Min. 25 ohm

Voltage Regulation

< ¡À1% (within 4% engine governing)

Build Up Voltage

Residual voltage at AVR terminal > 2VAC

Voltage Adjust Range

115/230 VAC ¡À15%

Thermal Drift

0.05% per¡ãC change in AVR ambient

Environment

Operation Temperature -20¡ãC~65¡ãC
Storage Temperature -40~85¡ãC
Relative Humidity Max. 90%
Vibration 1.5G @ 5~30Hz / 5.0G @ 30~500KHz

Dimensions

64.5 x 158.2 x 40.0 mm
