The Automatic Voltage Regulator (AVR) is an advanced electronic component that provides closedloop control of the generator’s output voltage.
Normal AVR supply power:2 auxiliary windings (X1, X2, ans Z, Z2). Shunt supply: 150V - 5060Hz. Rated overload current:10A, 10s.
Electronic built- in )overload, short circuit, and loss of sensing) protecting: If excitation current raises over 10 amps for more then 10 seconds, excitation current will drop automatically to about 1A.
To reset AVR protection, the generator must be stopped )or by cutting supply voltage to the AVR).
