JEENDA Automatic Voltage Regulator Controller AVR EA05A for Kutai

Feature:

• < ±0. 5% Regulation
• 220/380/440 VAC Programmable Input
• Rugged Compact Design
• With Under Frequency Protection
• Soft Start Voltage Ramping
• EMI Suppression
• Built-in High Capacity 5 Amp Fuse

Parameter:

• Sensing Input
• Voltage:220/380/440VAC, 1 phase 2 wire
• Frequency:50-60Hz nominal
• Voltage input:100-300VAC, 1 phase 2 wire output
• Voltage:max90VDC at 240VAC input
• Current:continuous 5A,intermittent 7A for 10 secs
• Resistance:12 Ω minimum, max 100Ω
• Regulation:+/-0. 5% RMS with 4% engine governing
• Voltage build-up: residual voltage at avr terminal >5VAC
• External Voltage Adjustment:+/-7% with 1k ohm 1-watt trimmer
