With intelligent integrated circuit chip control, Automatic circuit protection function
Output current flow automatic stop, automatic stop outside the output voltage is more than 10% of the rated voltage output load is too large or too short will automatically stop
Sensing/Power input
Voltage Jumper selectable 90-130V ac
Frequency 50-60 Hz nominal
Phase 1
Voltage Max 150V ac ,3 phase
Magnetic Field Output
Current DC< 6A
Resistance 15 ohms minimum
Pressure Regulating Accuracy <±1% RMS with 4% engine governing
